Plant Design Tutorial


With the exercises, you will learn how to design with Vertex G4Plant software.

  • The site has been created based on the principle of "Learning by doing" You can walk through each topic by following practical exercises. The exercises have been kept simple, but they will help you become familiar with the program and its tools, which you can then apply with your design work.
  • We recommend doing the exercises in number order.

Required skills

You should be familiar with archiving, part, and assembly modeling, before advancing to these exercises. You can learn the required skills by following these self-study materials: Interfaces and archiving and Basics of Mechanical Design

Version compatibility

These exercises and related models have been modeled by using version 27.0 (Vertex 2021).
