Vertex G4 Upgrades and Updates


Vertex G4 2024 release date is January 11, 2024


How to get a new version?

If your company is enrolled in our Support and Maintenance service, your company's Vertex G4 administrator that we have on record will receive an email containing a link to download the upgrade installation package, along with instructions and licensing information. The delivery starts on January 11, 2024. Emails will be sent by February 29, 2024.

If the message has not reached the right person, please contact your local Vertex representative to assist you.

Vertex Systems - Finland: order@vertex.fi

Which version do I have?

You can find Vertex software version at the top bar of the running application e.g. Vertex G4 2024 / 30.0.2.

  • The first number of the software version (e.g. 30) tells the major version, the second (0) intermediate version and the third (2) is the service pack number.



Compatibility of file formats between versions

You cannot read models or drawings created or edited with newer major versions in older major versions.

Software Licensing

You may need a new license for the Vertex G4 upgrade.

  • Find out which technique is used to manage the Vertex software licenses in your company.
  • Older licensing methods, such as HASP keys and Virtual IDs, will require an updated license file for each major version.
  • Refer to the installation instructions for software licensing procedures: Vertex G4 2024 licensing.



Co-operation

If you work with other Vertex users or your principal has Vertex and you provide them models and / or drawings, you should agree on a common date for the upgrade.

Network Server vs Single installation

Companies with more than one Vertex G4 license should use the network server installation so all designers can work with common models, drawings, and libraries if needed.

  • When using a network server, both the major version upgrades and service pack updates should be run on the network server, not on the workstations.
  • Workstations will update from the network server at the next re-start.

FLOW Connected Vertex G4

If Vertex G4 is connected to Vertex Flow both must be upgraded at the same time

In order to upgrade the Vertex Flow major version please contact Vertex Systems Oy.


Upgrades and Updates

New major versions are released once a year. These include new features and functionality enhancements.

New features included in recent versions can be found at the following links:

Vertex G4 2024 (30.0) (Latest)

Service packs are released about once a month. These include bug fixes and small enhancements. The latest Service pack includes all previously released service packs for the major version.

Service pack release notes can be found at the links below:

Vertex G4 2024 (30.0) Service Packs

Upgrade Instructions

Major version install and upgrade instructions

Vertex G4 2024 (30.0)


Identify the Major Version installation package

Full installation packages are compressed files named after the software version e.g.:

  • Vertex-G4-2024-30-0-0-en.zip
  • Vertex-G4-2023-29-0-00-en.zip

After unpacking the compressed file, you can either install a the Vertex version, upgrade the previous version or update the current version.


Identify the Service Pack installation package

Service packs are self-extracting files e.g.:

  • Vertex-G4-2024-30-0-en-update-1.exe
  • Vertex-G4-2023-29-0-en-update-01.exe

These updates are for internal patching of the current version. These cannot upgrade an old major version, and should never be used on a different major version than intended.
